Now it is time to:

Dependencies installation

Laravel comes with a default package.json file in order to build the front-end assets with Laravel Mix and Webpack packages. The aim of our project is to replace Laravel Mix with Vite, so let's clean our package.json to the minimal and remove all scripts and dependencies:

{
    "private": true
}

You can also delete the webpack.mix.js file

We can now install all the dependencies via yarn, but you can of course use npm if you prefer.

# Inertia Client Side (with Axios as a dependency) and its Vue 3 plugin
yarn add @inertiajs/inertia @inertiajs/inertia-vue3

# Vue 3
yarn add vue@next

# Tools for authoring Single File Components (SFCs) (with PostCSS as a dependency)
# Note: as of 3.2.13+, this package is included as a dependency of the main vue package
# yarn add @vue/compiler-sfc --dev

# Vite and its Vue 3 SFC plugin
yarn add vite @vitejs/plugin-vue --dev

# TypeScript and its Vue plugin
yarn add typescript @vuedx/typescript-plugin-vue --dev

Inertia configuration

We need a TypeScript file to boot our Inertia application, so let's create app.ts file in /resources/js/ (you can rename the previous default app.js - or name it like you want and adapt the other files accordingly - and delete the bootstrap.js file).

You can refer to the official documentation for more details.

For easy start, we will just create and mount a basic Vue / Inertia app:

import { createApp, h } from "vue"
import { App, plugin as inertiaPlugin } from "@inertiajs/inertia-vue3"
import "vite/dynamic-import-polyfill"

const el = document.getElementById("app")!

createApp({
  render: () =>
    h(App, {
      initialPage: JSON.parse(el.dataset.page!),
      resolveComponent: async (name: string) => {
        const page = (await import(`./Pages/${name}.vue`)).default;
        return page
      },
    }),
})
  .use(inertiaPlugin)
  .mount(el)

What it does

  • Import Vue and Inertia packages (and its Vue3 plugin)
  • Declare our root HTML element ID
  • Create the application, looking for Pages Vue Components (that replace standard Laravel Blade files) in /resources/js/Pages when rendering from Laravel Controller
  • Use the Inertia Vue3 plugin

Vite configuration

Here is the tricky part as we are discovering Vite, so take it as a draft that should be improved later on.

So, let's create a vite.config.ts in our project root folder:

import { ConfigEnv, defineConfig } from 'vite'
import vue from '@vitejs/plugin-vue'

export default defineConfig(({ command }: ConfigEnv) => {
  return {
    base: command === 'build' ? '/dist/' : '',
    publicDir: false,
    build: {
      manifest: true,
      outDir: "public/dist",
      rollupOptions: {
        input: {
          app: "resources/js/app.ts",
        },
      },
    },
    server: {
      strictPort: true,
      port: 3030,
      // https: true,
      hmr: {
        host: "localhost",
      },
    },
    plugins: [
      vue()
    ],
    optimizeDeps: {
      include: [
        "@inertiajs/inertia",
        "@inertiajs/inertia-vue3",
        "axios",
        "vue"
      ],
    },
  }
})

What it does

  • Import Vite and its Vue 3 SFC plugin
  • Define the configuration (Official Documentation)
    • base: web base path, according to the Vite command that tells us in which environment (development / production) we are:
      • production (command === 'build'): look for dist folder (in our /public folder) - you can name it like you want and adapt the other scripts it is used
      • development: empty string as we use Vite server
    • publicDir: folder used to serve static assets, we won't use it for now
    • build: options when we build for production environment
      • manifest: generate a manifest.json that contains the information of the files (JS, CSS) needed in our application with their hashed version
      • outDir: by default, Vite will empty the output folder on build, so we use a subfolder of the /public Laravel folder
      • rollupOptions: here we define the entry point of our application that will recursively call all our files (it uses Rollup.js that offers many options)
    • server:
      • strictPort: set to true to exit if port is already being used
      • port: set the port you want for your Vite server, it will be used later
      • hmr.host: here we set the host for our Hot Module Replacement
    • plugins: use the Vite Vue plugin
    • optimizeDeps.include: force a linked package to be pre-bundled (not sure if necessary for axios and vue packages)

TypeScript configuration

We create a tsconfig.json in our project root folder:

{
    "compilerOptions": {
        "target": "esnext",
        "module": "esnext",
        "moduleResolution": "node",
        "strict": true,
        "jsx": "preserve",
        "sourceMap": true,
        "resolveJsonModule": true,
        "esModuleInterop": true,
        "lib": [
            "esnext",
            "dom"
        ],
        "plugins": [
            {
                "name": "@vuedx/typescript-plugin-vue"
            }
        ]
    },
    "include": [
        "resources/js/**/*.ts",
        "resources/js/**/*.d.ts",
        "resources/js/**/*.vue"
    ]
}

What it does

  • Use default compiler options given by Vue
  • Use @vuedx/typescript-plugin-vue package to improve TypeScript features for .vue files
  • Defines the include folders: all .ts, .d.ts and .vue files in our resources/js/ folders

Scripts definition

All the configuration is set, we now need to define our Vite scripts in our package.json

    "scripts": {
        "dev": "vite",
        "build": "vite build"
    },

What it does

  • dev: start Vite server
  • build: build production bundles

You can name them like you want (if you rename build, you need to change the test on the command variable in the vite.config.ts file)

We can now start our development environment:

yarn dev

yarn dev

Or build for production:

yarn build

yarn build

Root View set up

To integrate Inertia and load our assets on the first page visit, we need a standard view Blade file. So we create app.blade.php in /resources/views/ folder (you can use and rename the default welcome.blade.php).

app.blade.php is the default view used by Inertia, you can change it in the Inertia Middleware or call Inertia::setRootView() in your code.

<!DOCTYPE html>
<html lang="{{ str_replace('_', '-', app()->getLocale()) }}">
    <head>
        <meta charset="utf-8">
        <meta name="viewport" content="width=device-width, initial-scale=1">

        @production
            @php
                $manifest = json_decode(file_get_contents(public_path('dist/manifest.json')), true);
            @endphp
            <script type="module" src="/dist/{{ $manifest['resources/js/app.ts']['file'] }}"></script>
            {{-- <link rel="stylesheet" href="/dist/{{ $manifest['resources/js/app.ts']['css'][0] }}"> --}}
        @else
            <script type="module" src="http://localhost:3030/@vite/client"></script>
            <script type="module" src="http://localhost:3030/resources/js/app.ts"></script>
        @endproduction
    </head>
    <body>
        @inertia
    </body>
</html>

What it does

  • To have Vite working in both development and production environments and include the related assets in the head, we need some little hack (to be improved):
    • Production: read the manifest.json file to get our app.ts build and versioned file location (same will apply for CSS that we will see later)
    • Development: include Vite client and call the Vite server to serve our application from the entry point /resources/js/app.ts (adapt here the Vite host of HMR and server port)
  • Include the @inertia Blade directive in the body

Time to play and display our first Page

All that remains to do is:

  • Create a Laravel Controller with its route
  • Create a Vue Page

Laravel

We will create a simple Controller, its only task is to render the Index Page (that Inertia will resolve in our /resources/js/app.ts and that will look for /resources/js/Pages/Index.vue file).

/app/Http/Controllers/IndexController.php

<?php

namespace App\Http\Controllers;

use Inertia\Inertia;

class IndexController extends Controller
{
    public function index()
    {
        return Inertia::render('Index');
    }
}

/routes/web.php

<?php

use App\Http\Controllers\IndexController;
use Illuminate\Support\Facades\Route;

Route::get('/', [IndexController::class, 'index'])->name('index');

Vue

We will start just displaying a welcome message and write something in the console.

/resources/js/Pages/Index.vue

<template>
  <div>
    <h1>Welcome</h1>
  </div>
</template>

<script lang="ts">
import { defineComponent } from "vue"

export default defineComponent({
  setup() {
    console.log("Page - Index")
  },
})
</script>

Or with the SFC <script setup> (compile-time syntactic sugar for using Composition API inside Single File Components: v3.vuejs.org/api/sfc-script-setup.html)

<script setup lang="ts">
console.log("Page - Index");
</script>

<template>
  <div>
    <h1>Welcome</h1>
  </div>
</template>

RUUUUUUN

Start Vite

yarn dev

Go to the web root of your project in a browser (problably http://localhost)

and...

TADAAAAAAAAAAA

And maybe should we validate production build

First we build our assets.

yarn build

To use this files, we need to do a little change to tell Laravel we want to use production assets. To do so, we change the environment in our .env from

APP_ENV=local

to

APP_ENV=production

Now refresh your browser and you can see that the production JavaScript files are loaded

TADADAAAAAAAAA


We'll do our best to provide source code of the serie on GitHub
